125
8009441/YN36/V3-0/2015-08| SICK OPERATING INSTRUCTIONS|GM35
Subject to change without notice
TECHNICAL DATA, CONSUMABLES AND SPARE PARTS
10.3.7 Spare parts for purge air unit
10.3.8 Fixing accessories
Fixing accessories for purge air fixture - flange
Fixing accessories for SR-unit
Part No. Name
5 306 090 Air filter, complete, Europiclon
5 306 091 Filter element, Micro-Top-Element
4 708 971 Distributor, 2xDN40
4 022 766 Purge air hose, DN40, length 5 m
5 700 520 Hose clamp, DN40-60x12
Part No. Name
5 700 457 Screw, 6 Kt M16x60-A2
5 700 482 Washer, A17-A2
5 700 471 Nut, 6 Kt M16 A2
5 700 480 Lock washer, A16
Part No. Name
5 700 484 Cup springs A25
5 700 472 Nut, SSI M12
5 700 494 Spherical washer
2 017 329 Hinge pin for GM35 flange fixture
4 023 743 Sealing tape
