Automation System CNC 61.00
:
20 Hardware Description CNC 0610510/12 CNC 61.00
The CNC 61.00 can be expanded by supplementary plug-in modules:
X two analog inputs, 12 bits
X two analog outputs, 12 bits
X INTERBUS interface
X PROFIBUS interface
X two serial interfaces
X connection of two active/passive transducers
X battery-buffered RAM expansion and real-time clock
Due to the digitization, nearly all parameters can be adjusted via the software.
Possible arising errors are indicated as error code by LEDs on the front panel. Eval-
uated errors are, among others, overvoltage, undervoltage, tracking error, limit
switch and emergency stop.
5.2 Programming
Executable programs (application program) are created with the CNC 61.00 system
software on a PC.
Machine functions are programmed in application programs consisting of command
sequences that specify, for example, movement, PLC functions or reactions to user
inputs. The CNC 61.00 executes programmed commands while the application pro-
gram is running.
The commands have a uniform structure and permit compact programming. The
user will only need some commands due to the sophisticated command repertoire.
For parameterizing nut setting and pressing processes in a comfortable way, special
software interfaces are available.
5.3 Performance Features
Emphasis is put on the following performance features of the SIEB & MEYER auto-
mation system CNC 61.00:
X single-phase power supply for lower motor powers in the 230 V
AC
version
X galvanic separation between control and power components
X extensive protective functions for motor and CNC module, such as evalu-
ation of the thermal contact, I2t, etc.)
X output for collective fault messages
X short circuit-proof (phase to phase, phase to ground)
X optimum evaluation of the encoder signals
X highly constant running, even at low speeds
X high dynamics
X self-controlled resolver adaptation and adjustment of up to 1.024 angle
pulses (version with resolver evaluation)
