Option Modules
CNC 61.00 Hardware Description CNC 0610510/12 83
10.3 Option Module 061020045X
The option module 061020045X can comprise the following functionality and/or their
combination:
X INTERBUS interface
X two active transducers,
X two passive transducers,
X two serial interfaces
X two analog inputs,
X battery-buffered RAM and real-time clock.
The following table shows the combinations which are available at the moment:
On the front panel of the option module, only the connections required for the respec-
tive variant are provided.
Option
2 x COM INTERBUS 500 kBit INTERBUS 2 MBit 2 transducers passive 1/2mV/ V 2 transducers active
"5 V
2 analog inputs "10 V RAM and RTC
Variant
61020045A x x x x
61020045B x x x x
61020045C x x
61020045D x x
61020045E x x x x
L
Please take into account that a later upgrading of the option modules
won't be possible.
LEDs
X14
X13
connections for two active/passive transducers (beginning on
page 86) and for
two analog inputs (page 91)
COM3
COM2
X12
X11
serial interface,page 90
INTERBUS, page 84
X14
X13
COM3
COM2
X12
X11
CC
RD
BA
