CNC 61.00 Hardware Description CNC 0610510/12 67
10 Option Modules
10.1 Option Module 061020043X
The option module 061020043X can comprise the following functionality and/or their
combination:
X two additional serial interfaces with RS232 specification; one of these also with
RS485 specification
X PROFIBUS interface
X two independent transducer inputs for passive transducers (350/700 Ω, 1 mV/V
or 2 mV/V)
X two independent transducer inputs for active transducers (± 12 V supply,max.
200 mA, ± 3.5 V, ± 5 V and ± 10 V, calibration outputs with TTL level)
X two independent analog inputs (± 10 volts input voltage, 12 bits resolution)
X 128 kByte battery-buffered RAM and real-time clock
The following table shows the combinations which are available at the moment:
Option
2 x COM (RS232) 2 transducers passive 1/2mV/ V 2 transducers active
"5 V
2 transducers active
"3,5 V
2 transducers active
"10 V
2 analog- inputs
"10 V
PROFIBUS RAM and RTC
Variant
61020043 A x x x x
61020043B x x x x
61020043E x
61020043F x x
61020043G x
61020043H x x
61020043 I x x x x
61020043J x x x x
L
Please take into account that a later upgrading of the option modules
won't be possible.
