Functional Description of the Connectors/Interfaces
CNC 61.00 Hardware Description CNC 0610510/12 47
8.2.7.1 X7 - MODLINK, ETHERNET, CAN
X female RJ45 connector
8.2.7.2 X8 - MODLINK, CAN
X female RJ45 connector
8.2.7.3 X9 - CAN, Analog Input
X female RJ45 connector
Pin Designation Function
1 Ethernet_Tx+
Ethernet transmission signal
2 Ethernet_Tx-
3 Ethernet_Rx+ positive Ethernet receiving signal
4CAN+
Data signal
5CAN-
6 Ethernet_Rx- negative Ethernet receiving signal
7MODLINKIn+
MODLINK input signal
8MODLINKIn-
87654321
Pin Designation Function
1 NC Not assigned
2 VCC_EXT Supply for terminating resistors
3 GND_EXT Ground
4CAN+
Data signal
5CAN-
6 NC Not assigned
7 MODLINKOut+
MODLINK output signal
8 MODLINKOut-
87654321
Pin Designation Function
1 VCC_EXT Supply for terminating resistors
2 NC Not assigned
3 AnalogIN+ Positive analog input signal
4CAN+
Data signal
5CAN-
6 AnalogIN- Negative analog input signal
7 NC Not assigned
8 GND_EXT Ground
87654321
