Technical Data
CNC 61.00 Hardware Description CNC 0610510/12 35
7.2 Supply Voltage 400 V
AC
Module Type
0610510/12xx
1
Current range/voltage range DF EF SF
Main supply
2
3 x 400 V
AC
-10% / +26%; 50 Hz / 60 Hz
Logic supply two-phase, 400 V
AC
-10% / +26%; 50 Hz / 60 Hz
same potential as main supply
Max. voltage phase/ground 280 V
AC
Resultant intermediate circuit voltage 565 V
DC
-10% / +26%
Rated current of the ventilated output stage
3, 4
7 A
S
5 A
eff
7 A
S
5 A
eff
7 A
S
5 A
eff
Max. values of the output stage at rated current 3 x 400 V
AC
+26% at 0 to 1600 Hz
Peak current
3
of the output stage for max. 5 s
20 A
S
40 A
S
60 A
S
Switch-off temperature of the output stage 75 °C
Rated direct current of the integrated power
module, single-phase supply
not possible
Rated direct current of the integrated power
module, three-phase supply
7 A
Peak direct current of the integrated power mod-
ule, three-phase supply f > 15Hz
50 A for max. 1 s
Mains connection power of the integrated power
module, 400 V
AC
single-phase supply
not possible
Mains connection power of the integrated power
module, 400 V
AC
three-phase supply
2.8 kVA
Power consumption logical unit max. 20 W
power Unit max. 5 % of the electrical rated power of the motor, but minimum 20 W
External protection 6 A gL/gG
Internal ballast resistor 44 Ω / 10 W
Min. external ballast resistor 33 Ω
Max. activation time of the ballast circuit 750 ms
Temperature range 5°C to 60°C at a maximum of 95 % relative humidity (no moisture conden-
sation) 100 % rated current up to 40°C
Overvoltage turn-off limit 850 V
DC
Undervoltage turn-off limit 40 V
DC
Chopper turn-off limit 800 V
DC
System of protection IP20
Nominal current reduction:
X at ambient temperatures >40° C
X at heights > 1,000 m above mean sea level
-1.5% per 1° C
-15% per 1,000 m
Weight 3.2 kg (0610510xx); 3.6 kg (0610512xx)
Width 65.00 mm (0610510xx); 85 mm (0610512xx)
Height (mounting device included) 318.00 mm
Depth 173.00 mm
1
xx is replaced by the respective code letter of the current range and voltage range (e.g. DF)
2
only three-phase supply at directly grounded mains (see documentation "Unit Assembly Complying EMC", chapter "Connec-
tion to different Supply System Types")
3
chopper not active
4
at heights < 1,000 m (3.281 ft) M.S.L.
