SIEB & MEYER CNC 61.00 - Page 34

Technical Data
:
34 Hardware Description CNC 0610510/12 CNC 61.00
1
xx is replaced by the respective code letter of the current range and voltage range (e.g. DC)
2
single-phase or three-phase supply is possible (see documentation "Unit Assembly Complying EMC", chapter "Connection to
different Supply System Types")
3
chopper not active
4
at heights < 1,000 m (3.281 ft) above M.S.L.
L
Rated and peak currents are sine crest values. Specifications apply
for 8 kHz operating frequency of the output stage.
L
The device must be mounted in a vertical position!
