Functional Description of the Connectors/Interfaces
:
58 Hardware Description CNC 0610510/12 CNC 61.00
8.3.8 Coding Selector - ID
The coding selector serves for adjusting the axis address of the module. If the axis
address is to be higher than 14, set the ID switch to F (15 decimal) and modify the
address in the type plate of the axis by using the supplied software. In other cases,
the axis address of the device is modified if the coding selector is set to a value un-
equal F.
