SIEB & MEYER CNC 61.00 - Status Indications FC0 to FC3 (Green and Red); Indication of Malfunctions - RIO; Status of Controller - RON; Operation Indication - CNC

Functional Description of the Connectors/Interfaces
:
56 Hardware Description CNC 0610510/12 CNC 61.00
8.3.1 Status Indications FC0 to FC3 (green and red)
8.3.2 Indication of Malfunctions - RIO
8.3.3 Status of Controller - RON
8.3.4 Operation Indication - CNC
8.3.5 Indication "Remote Control“ - REM
LEDs Status Possible reason
DE
EE
FC0 is green PI LIMIT and Controller On are active
DD
DD
FC0 to FC3 is alternately red and green no operating system (firmware) is provided
EE
EE
LED RIO Meaning
D
no controller error
E
controller error
LED RON Meaning
D
controller ON
E
controller Off
LED CNC Meaning
D
CNC operation
E
REMOTE operation
LED RIO Meaning
E
CNC operation
D
REMOTE operation
