101 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Detail pages: Inputs and outputs 01.02.2010
Parameter Range Function
Reliability – OK.
– Other
– Process Error
– Config err
Reliability state for hardware.
– Basis controller: Calibration lacking (output defec-
tive).
Extension module POL955: Calibration lacking
(Output defect) or communication to base control-
ler unavailable or the output is incorrectly config-
ured.
– Basis controller: Process error in program.
Extension module: Message no available.
– Basis Controller: Output configured incorrectly.
Extension module: Message no available.
Active prio – Out of serv.
– Prio1
– ….
– Prio16
– Default
Displays the wired Prio elements currently on the
output.
Special infos --- Go to Special info page (at access levels 6, 4 and 2
only).
Priority array --- Go to Priority array page (at access levels 6, 4 and
2 only).
6.4.2 Special information
• Read: Levels 6, 4 and 2.
• Write: Not writable.
Parameter Range Function
Physical value – Off
– Stage1
– Stage2
– Stage3
Value on output. Only differs from present value
with out of service intervention via BACnet.
Disable OffNormal
– Passive
– Active
The OffNormal alarm is disabled:
– Alarming is enabled.
– Alarming is switched off.
Communication
infos
--- Not enabled for multistate outputs.
6.4.3 Priority array
• Read: Levels 6, 4 and 2.
• Write: Read only.
Parameter Range Function
Default Off / Stage1 / Stage2 / Stage3 / NULL Replacement value, when no priority is ac-
tive. NULL means the Prio is disabled.
Prio 01 Fix Off Value for priority 1 (always Off): Plant is
locked during configuration or during control-
Access level
Parameter
Access level
Parameter
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 101
