219 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Time scheduler 01.02.2010
Main Index > Unit > Inputs > Element Group > Element > Special infos
Parameter Function Value range Unit Standard R S Link
Value comm Present value from communications. Depends on hardware. 6 Section:
6.5.3
Reliability HW Present reliability of hardware value. Depends on hardware. 6
Reliability comm Present reliability of value from communica-
tions.
Depends on hardware. 6
Disable OffNormal Display OffNormal alarms:
No alarm pending.
Alarm pending.
Passive
Active
6
ToOffNormal Date and time the last off normal alarm
occurred.
Day of week,
dd.mm.yyyy hh:mm:ss
6
ToFault Data and time last fault alarm (Reliability <>
0) occurred.
Day of week,
dd.mm.yyyy hh:mm:ss
6
ToNormal Date and time last alarm was reset. Day of week,
dd.mm.yyyy hh:mm:ss
6
Communication infos Information on the communication status
for elements.
No error.
Fault.
Comm OK
Noch nicht
implementiert.
6
18.6 Detail pages: Digital inputs
18.6.1 General
Main Index > Unit > Inputs > Digital inputs > Element
Parameter Function Value range Unit Standard R S Link
Present Value Present input value. Depends on hardware. 6 4
Reliability (Basis
Controller)
Reliability state for hardware.
Calibration lacking. Controller must be re-
turned to the factory.
Internal fault.
Input not configured.
OK.
Other
Process Error
Config Error
6 4
Reliability (Extension
Modul POL 955)
Reliability state for hardware.
Calibration lacking. Controller must be re-
turned to the factory; internal fault or input
not configured.
OK.
Other
6 4
Section:
OffNormal Displays OffNormal alarms:
No alarm.
Alarm
Passive
Active
6 4
6.6.1
Operating hours Number of operating hours for the output. 0... [h] 6 4
Operating seconds
(Reset)
Number of operating seconds for the out-
put. Enter 0 seconds to reset operating
hours to 0.
0... [s] 6 4
Last op hours reset Date and time for the last time operating
hours was reset.
Wday, dd.mm.yyy
hh:mm:ss
6 4
Time delay Alarm time delays for off normal alarms. 0…65535 [s] 6 4
Special settings Go to special settings page. 4
Special infos Go to special info page. 6
18.6.2 Special settings
Main Index > Unit > Inputs > Digital inputs > Element > Special settings
Parameter Function Value range Unit Standard R S Link
Out of service Take input offline for manual entry of state.
The input is in Auto mode.
Input is out of service: The present value
for the hardware has not influence on the
input.
Passive
Active
4 4
Present value Present value. You can enter a value for
out of service = active.
Text abhängig von der
Hardware.
4 4
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 219
