Siemens Standard application AHU CE1P3977en_02
Building Technologies Examples 01.02.2010
16 Examples
A sample configuration is planned for the next documentation version.
17 HMI
17.1 Overview
The following applies to all tables:
15. Column R: Required read access level
Empty means that it can always be read.
16. Column W: Required write access level or to go to next level
Empty means go to or write is always permitted
X stands for readable value only (e.g. actual value).
17.2 Start page
Start page
Parameter Function Value range Unit Standard R S Link
Password enter Jumpline to enter the Password
Main index
Jumpline to main index Page for the hole
Unit
Main overview
Jumpline to the short overview Page for the
Unit
Manual operation
Actual Status from Manual operation (if the
configuration is done you see only one of
this two lines)
Manual operation
Actual Status from Manual operation (if the
configuration is done you see only one of
this two lines)
Act operating Mode Actual operating Mode from the Unit
Outside air temp
Actual value from the Outside air
Temperature
-64.0…64.0 °C
Supply air temp
Actual value from the Supply air
Temperature
-64.0…64.0 °C
Act room tmp
Actual value from the for controlling used
Room Temperature
-64.0…64.0 °C
Exhaust air temp
Actual value from the Exhaust air
Temperature
-64.0…64.0 °C
17.3 Main index
Main Index
Parameter Function Value range Unit Standard R S Link
Unit Main entry into the HMI for all Values
Global functions Jumpline to global functions
Alarm handling Jumpline to alrm handling
Integrations
Jumpline to Integrations Energy meter and
Room units
System overview Jumpline to system overview
Overview IO
confi/rawvalues
Jumpline to Overview for all IO settings and
raw Values
4
Configuration
Indicator if configuration is finished.
Jumpline to configuration pages
Not done
done
4
