Siemens Climatix Series User Manual

235 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Appendices 01.02.2010
20.3 Navigation illustrations
Start page > Main index / Main overview
->Unit--------------------
->Global functions----
->Alarm handling-----
->System overview---
->Configuration--------
Main index
System overview
Unit
-> Main overview----------
-> Inputs
-> Outputs
-> Operating mode
-> Setpoints/settings
-> Damper control
-> Fan control
-> Temp control
-> Humidity control
-> Air quality control
-> Auxiliary
-> Loop controllers
-> Operation hours
Configuration
Configuration by
-> Configuration 1
-> Configuration 2
-> Configuration IO’s
-> Check config IO’s
Doubled
Not configured
-> Integrations
RoomUnit 1
RoomUnit 2
-> Language selection
-> Application Info
-> Save / restore
-> Communication
-> Target
-> All system settings
Su/Wi caluclation
Manual mode
Enable manual alarm
Enable comm test
Communication test
Global functions
->Password enter
->Main Index--------------
->Main overview---------
Manual Operation
Act operating mode
Outside air temp
Supply air temp
Act room temp
Exhaust air temp
Start page
Main overview
->Act operating mode
->Time switch program
->Outs air tmp
->Outs air hum rell
->Outs air hum abs
->Outs aur enthalpy
▼
Main overview
Alarm handling
-> Alarm acknowledge
-> Danger (A)
-> Critical (A)
-> Low (B)
-> Warning (C)
-> Alarm outp 1 select
▼
Start page
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 235

Siemens Climatix Series Specifications

General

Application	HVAC control
Communication Protocols	BACnet, Modbus, KNX
Inputs	Analog and digital inputs
Outputs	Analog and digital outputs
User Interface	web interface
Power Supply	24 V AC
Protection Class	IP20
Mounting	DIN rail mounting
