Siemens Climatix Series User Manual

184 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
Main Index > Configuration > Configuration 2
Parameter Function Value range Unit Standard R S Link
Aux tmp sensor Auxiliary Temperature sensor No
Yes
No 4
Aux TSP output Auxiliary Output with own Scheduler No
Yes
No 4
Aux A outp fan Auxiliary analog Output which is setted
according to the actual Fan Step the
No
Yes
No 4
Aux op mode indicat Auxiliary Output which Indicate the selected
Operation Mode
No
Yes
No 4 Section:
15.2
Configuration 2 If Configuration 2 is done this must be setted
to done
Done
NotDone
NotDone 4
Reset required !! After Configuration 2 done a reset is needed
for take away not needed Lines from
Configuration 2
Passive
Active
Passive 4
17.8 Configuration I/Os
Main Index > Configuration > Configuration IO’s
Parameter Function Value range Unit Standard R S Link
Temperatures Jumpline to Configuration IO’s
Temperatures
Pressures/Flows Jumpline to Configuration IO’s
Pressures/Flows
4
Humidity Jumpline to Configuration IO’s Humidity 4
Digital inputs Jumpline to Configuration IO’s digital Inputs 4
Digital alarms Jumpline to Configuration IO’s digital
alarms
4
Other Jumpline to Configuration IO’s Air Quality,
External setpoint
4
Outputs damper Jumpline to Configuration IO’s Supply-,
Exhaust-, Firedampers
4
Outputs fans Jumpline to Configuration IO’s Exhaust-,
Supply Fan
Section:
15.3.1
Outputs tmp control Jumpline to Configuration IO’s for all
Temperatur sequence relatet Elements like
Heating, Cooling
Outputs humidifier Jumpline to Configuration IO’s digital
alarms
Outputs auxiliary Jumpline to Configuration IO’s digital
alarms
Outputs alarm Jumpline to Configuration IO’s digital
alarms
Configuration IO’s If Configuration IO’s is done this must be
setted to done for internal lockings
Done
NotDone
NotDone 4
Reset required !! After Configuration IO’s is setted to done, a
reset is needed before starting the
parametrising from the Airhandling Unit
Passive
Active
Passive 4
17.8.1 Temperatures
Main Index > Configuration > Configuration IO’s >Temperatures
Parameter Function Terminal Type R S Link
HW IO: Pos: Type:
Supply air Supply air temperature NUsd,Comm,X1…X28 Pt1k…NTC10k 4
Room Room temperature 1 NUsd,Comm,X1…X28 Pt1k…NTC10k 4
Room 2 Room temperature 2 NUsd,Comm,X1…X28 Pt1k…NTC10k 4
Exhaust air Exhaust air temperature NUsd,Comm,X1…X28 Pt1k…NTC10k 4
Outside air Outside air temperature NUsd,Comm,X1…X28 Pt1k…NTC10k 4 Section:
Heating frost Heating frost protection temperature NUsd,Comm,X1…X28 Pt1k…NTC10k 4
15.3.2
Heat recovery water Heat recovery water temperaure NUsd,Comm,X1…X28 Pt1k…NTC10k 4
Extract air Extract air temperature NUsd,Comm,X1…X28 Pt1k…NTC10k 4
Hrec supply air Heat recovery supply temperature NUsd,Comm,X1…X28 Pt1k…NTC10k 4
Supply air 2 Supply air 2 temperature (needed if Htg 2
and/or Clg 2 have own Sequence
NUsd,Comm,X1…X28 Pt1k…NTC10k 4
Heating 2 frost Heating 2 frost temperature NUsd,Comm,X1…X28 Pt1k…NTC10k 4
Auxiliary Auxiliary temperature NUsd,Comm,X1…X28 Pt1k…NTC10k 4
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 184
