Siemens Climatix Series User Manual

188 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
17.8.10 Outputs humidifier
Main Index > Configuration > Configuration IO’s > IO conf hum outp
Parameter Function Value range Unit Standard R S Link
Humidifier AO IO Position Humidifier analog output NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4
Section:
Humidifier DO IO Position Humidifier Command NUsd,Comm,DO1...DO2
4
NUsd 4
15.3.11
Humidifier pump DO IO Position Humidifier pump NUsd,Comm,DO1...DO2
4
NUsd 4
17.8.11 Outputs auxiliary
Main Index > Configuration > Configuration IO’s > IO conf aux outp
Parameter Function Value range Unit Standard R S Link
Auxiliary A outp IO Position Auxiliary analog Output NUsd,Comm,X3...X28,
AO1...AO22
NUsd 4
Section:
TSP output DO IO Position Auxiliary Scheduler Output NUsd,Comm,DO1...DO2
4
NUsd 4
15.3.12
Aux op mode ind DO IO Position Digital Output for Auxiliary
Operation Mode Indicator
NUsd,Comm,DO1...DO2
4
NUsd 4
17.8.12 Outputs alarms
Main Index > Configuration > Configuration IO’s > IO conf alarm outp
Parameter Function Value range Unit Standard R S Link
Alarm DO1 IO Position alarm High Class NUsd,Comm,DO1...DO2
4
NUsd 4 Section:
Alarm DO2 IO Position alarm Low Class NUsd,Comm,DO1...DO2
4
NUsd 4
15.3.13
17.9 Check config I/Os
Main Index > Configuration > Check config IO’s
Parameter Function Value range Unit Standard R S Link
Not config IO Displays whether there are unassigned
I/Os.
No
Yes
1st notconfig IO pos Displays the position of the first unassigned
I/O.
0, 1, ...
Doubled config IO Displays whether hardware input or outputs
are occupied in duplicate.
No
Yes
Doubled config IO’s Displays positions of the first double occu-
pancy.
Doubled config IO
pos
Displays the first double occupied input or
output (exception: DO).
XO1...XO28
Doubled config DO
pos
Displays first double occupied DO. DO1...DO24 Section:
15.4
Not used xIO Displays number of unused universal in-
puts/outputs.
0... pcs pcs
Not used DI Displays the number of unused digital in-
puts.
0... pcs pcs
Not used AO Displays the number of unused analog
outputs.
0... pcs pcs
Not used DO Displays the number of unused digital out-
puts.
0... pcs pcs
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 188
