Siemens Climatix Series User Manual

180 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
Main Index > Configuration > Configuration 1 --- Functions
Parameter Function Value range Unit Standard R S Link
Heat recovery Choose the Heat recovery Unit No
Wheel
PlateExch
Water
Wheel 4
Heating Water Heating
Yes = Heating enabled
PreHeat = Heating + Preheating function
from the Heatingregister
No
Yes
Yes+PreHeat
Yes 4
Electrical heating Choose the Electrical heating Coil
Only one analog Output is enabled
1 step = 1 digital Output
2 step = 2 digital Outputs
3 step = 2 digital Outputs
No
Analog
1step
2step
3step
No 4
Cooling Cooling
If a Dx Cooler is choosed, the analog Output
has to be disabled seperately in IO Config if
not needed
No
Water
Dx 1Step
Dx 2Steps
Dx 3Steps
No 4
Humidity control Humidity control
Only Humidification
Only Dehumidification
Humidification and Dehumidification
No
Hum
DeHum
Hum+DeHum
No 4
Heating 2 Additionally Water Heating
Yes = Heating enabled
PreHeat = Heating + Preheating function
from the Heatingregister
No
Yes
Yes+PreHeat
No 4
El Heating 2 Choose the additionally Electrical heating
Coil
Only one analog Output is enabled
1 step = 1 digital Output
2 step = 2 digital Outputs
3 step = 2 digital Outputs
No
Analog
1step
2step
3step
No 4 Section:
0
Cooling 2 Additionally Cooling
If a Dx Cooler is choosed, the analog Output
has to be disabled seperately in IO Config if
not needed
No
Water
Dx 1Step
Dx 2Steps
Dx 3Steps
No 4
Fire damper Fire damper
Follow Unit= If Unit switch Off Damper close
No
Yes
FollowUnit
No 4
Configuration 1 If Configuration 1 is done this must be setted
to done for internal lockings
Done
NotDone
NotDone 4
Reset required !! After Configuration 1 is setted to done, a
reset is needed before entering
Commisioning 2
Passive
Active
Passive 4
17.7 Configuration 2
Main Index > Configuration > Configuration 2
Parameter Function Value range Unit Standard R S Link
Night cooling Activate the Night cooling function No
Yes
No 4
Tmp start Enables Unit start in Unoccupied Mode
according to Temperatur Difference between
the Room and a separate Setpoint
In case of a Htg demand
In case of a Clg demand
In case of a Htg or Clg demand
No
Htg
Clg
Htg+Clg
No 4
Boost Enables Unit start in Unoccupied Mode
according to the next start command from
sheduler
In case of a Htg demand
In case of a Clg demand
In case of a Htg or Clg demand
No
Htg
Clg
Htg+Clg
No 4
Tmp start/OSSTP blk Block in Case of Tmp start or Boost
The Damper (bypass Damper is needed)
The Exhaust fan and Damper (bypass
Damper is needed)
No
Damper
Damper+Fan
No 4 Section:
15.2
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 180

Siemens Climatix Series Specifications

General

Application	HVAC control
Communication Protocols	BACnet, Modbus, KNX
Inputs	Analog and digital inputs
Outputs	Analog and digital outputs
User Interface	web interface
Power Supply	24 V AC
Protection Class	IP20
Mounting	DIN rail mounting
