Siemens Climatix Series User Manual

216 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Time scheduler 01.02.2010
18.3.4 Priority array
Main Index > Unit > Outputs > Digital outputs > Element > Priority array
Parameter Function Value range Unit Standard R S Link
Default Replacement value, when no priority is
active.
Off
On
NULL
6 X
Prio 01 Value for priority 1. Off
On
NULL
6 X
Section:
6.3.4
... ... ... 6 X
Priority 16 Value for priority 16. Off
On
NULL
6 X
18.4 Detail pages: Multistate outputs
18.4.1 General
Main Index > Unit > Outputs > Digital outputs > Element
Parameter Function Value range Unit Standard R S Link
Manual operation Manual operation on element (e.g. fan).
NULL: Auto; The program controls the out-
put.
Off
Stage1
Stage2
Stage3
NULL
4 4
Present Value Present value for output. NULL
Off
Stage1
Stage2
Stage3
6 4
Section:
Reliability Reliability state for hardware. OK.
Other
Process error
Config err
6 4
6.4.1
Active prio Displays the wired Prio elements currently
on the output.
Out of serv.
Prio1
….
Prio16
Default
6 4
Special infos Go to special info page. 6
Priority array Go to priority array page. 6
18.4.2 Special information
Main Index > Unit > Outputs > Digital outputs > Element > Special settings
Parameter Function Value range Unit Standard R S Link
Physical value Value on output. Only differs from present
value with out of service intervention via
BACnet. OK?
Off
Stage1
Stage2
Stage3
6
Section:
Disable OffNormal Display OffNormal alarms:
No alarm pending.
Alarm pending.
Passive
Activ
6
6.4.2
Communication infos Not enabled for multistate outputs.
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 216
