Siemens Standard application AHU CE1P3977en_02
Building Technologies Functions 01.02.2010
5.10.5 Max limitation fan
Direct expansion evaporator is enabled:
Main Index > Configuration > Configuration 1 > Cooling = DX...
Main Index > Configuration > Configuration 1 > Cooling 2= DX...
Main Index > Unit > Temp control > Cooling > Max limitation fan
Main Index > Unit > Temp control > Cooling 2 > Max limitation fan
Parameter Range Function
Set the maximum allowable expansion evaporator output
for the given active fan stage. The value limits the maxi-
mum possible refrigeration demand. The settings depend
on expansion evaporator and fan output.
Must be clarified with the manufacturer as required!
Fan stage 1 0...100 [%] Allowed expansion evaporator output when the fan is op-
erating on stage 1 or using the setpoint with the setpoint
for stage 1.
Fan stage 2 0...100 [%] Allowed expansion evaporator output when the fan is op-
erating on stage 2 or using the setpoint with the setpoint
for stage 2.
Fan stage 3 0...100 [%] Allowed expansion evaporator output when the fan is op-
erating on stage 3 or using the setpoint with the setpoint
for stage 3.
FanStage1 = 30 %
StartStage2 = 40 %
In this case, the controller output for fan state 1 is limited to 30%. So that the
switch-on point of 40% for expansion evaporator stage 2 is never achieved.
5.11 Humidity control
5.11.1 General
This section described parameters and settings relating to humidification and de-
humidification.
The required sensors and functions are enabled in configuration 1, configuration 2
and configuration I/Os.
Cooling must also be enabled for dehumidification.
Main Index > Configuration > Configuration 1
Parameter Range Function
Room hum sensor – No
– Yes
Room humidity sensor.
Supply air hum sensor – No
– Yes
Supply air humidity sensor.
Outs air hum sensor – No
– Yes
Outside air humidity sensor.
Cooling –
– No
– Water
– DX 1step
Only required for dehumidification!
– No (additional) cooling register.
– (additional) cold water register.
– (additional) 1 step direct expansion evaporator aggre-
Prerequisite
Parameter
Example
Prerequisite
Enable
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 83
