Siemens Climatix Series User Manual

214 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Time scheduler 01.02.2010
18.2 Detail pages: Analog outputs
18.2.1 General
Main Index > Unit > Outputs > Analog outputs > Element
Parameter Function Value range Unit Standard R S Link
Manual operation Enter the value. Function enabled by enter-
ing a value.
0...100 [%]
Manual operation Status and reset after NULL.
NULL: Auto; The program controls the out-
put.
Active: A value entered in the upper line.
NULL
Active
Present Value Present value for output. 0…100 [%] 6 4
Reliability Reliability state for hardware. OK.
Other
Process error
Config err
6 4
Section:
6.2.1
Active prio Displays the wired Prio elements currently
on the output.
Out of serv.
Prio1
….
Prio16
Default
6 4
Special settings Go to special settings page. 4
Special infos Go to special info page. 6
Priority array Go to priority array page. 6
18.2.2 Special settings
Main Index > Unit > Outputs > Analog outputs > Element > Special settings
Parameter Function Value range Unit Standard R S Link
Msg class fault Set alarm class (and groups A, B, C):
Set the Unit in Stop Mode
Set the Unit in Off Mode
Only Message
Only Message
No Message, no Alarm
Danger (A)
High (A)
Low (B)
Warning (C)
No alarm
4 4
Section:
6.2.2
High limit Upper limit of output signal. 0…100 [%] 4 4
Low limit Lower limit of output signal. 0…100 [%] 4 4
18.2.3 Special information
Main Index > Unit > Outputs > Analog outputs > Element > Special infos
Parameter Function Value range Unit Standard R S Link
Physical value Value on output. Only differs from present
value with out of service intervention via
BACnet. OK?
0…100 [%] 4
Disable OffNormal
MMI-Texte so OK?
Check: The output is disabled by an alarm.
Example: Value greater than high limit
value:
Output OK.
Output switched off.
Passive
Active
4
Section:
6.3.3
ToOffNormal Date and time the last off normal alarm
occurred.
Day of week,
dd.mm.yyyy hh:mm:ss
4
ToFault Data and time last fault alarm (Reliability <>
0) occurred.
Day of week,
dd.mm.yyyy hh:mm:ss
4
ToNormal Date and time last alarm was reset. Day of week,
dd.mm.yyyy hh:mm:ss
4
Communication infos Not enabled for analog outputs. 4
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 214

Siemens Climatix Series Specifications

General

Application	HVAC control
Communication Protocols	BACnet, Modbus, KNX
Inputs	Analog and digital inputs
Outputs	Analog and digital outputs
User Interface	web interface
Power Supply	24 V AC
Protection Class	IP20
Mounting	DIN rail mounting
