20.2 Diagnostic tables for check I/O
The clear text from the following tables cannot be configured, but is required for a
function as well as determining if inputs or outputs are occupied in duplicate.
1rst notconf IO Pos = 82 => Input external control 2 is not assigned an input
(Nusd).
Caution: The plant is locked against switch on!
Doubled config I/O = Yes
Doubled config I/Os = 82 81
Doubled conf I/O pos = DI3
Inputs External contrl 1 and 2 were assigned the same output DI3.
Caution: The plant is locked against switch on!
Name Type Position
(IO
Check)
Name Type Position
(IO
Check)
Temperature supply AI 1 Temperature Aux AI 12
Temperature room 1 AI 2 Pressure supply AI 21
Temperature rum 2 AI 3 Pressure return AI 22
Temperature return AI 4 Flow supply AI 23
Temperature out AI 5 Flow return AI 24
Temperature frost AI 6 Pressure over recovery AI 25
Temperature water recovery AI 7 Humidity supply AI 31
Temperature exhaust AI 8 Humidity room AI 32
Temperature supply after recovery AI 9 Humidity out AI 33
Temperature supply Extra seq. AI 10 Air quality AI 35
Temperature frost Extra heat AI 11 External setpoint AI 36
Example 1
Example 2
Analog inputs
