Siemens Climatix Series User Manual

239 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Appendices 01.02.2010
20.4 Parameter list room unit
Parameter
Gruppe/ID
Description acces level
for writing
S1 Diagnostic/Reset 6
S2 Device/AcknowledgeAll 2
S11 Addr building 4
S12 Addr line 4
S13 Addr device 4
S20 Presence time 6
S21 Apartment 4
S22 AlarmMode 4
S23 OffIsBlckd 6
S24 Displayed RoomTemperature 6
S25 Back2Auto Off-Eco 6
S26 Back2Auto Off-Cmf 6
S27 Back2Auto Eco-Cmf 6
S28 Back2Auto Cmf-Eco 6
S29 Back2Auto Cmf-Off 6
S30 Back2Auto Eco-Off 6
S31 Manual control 4
S32 Heatrecovery display limitation 4
S33 Setpoint range +/- 4
S34 Setpoint increment 4
S35 Time format 4
A1 Actual operating Mode X
A2 Actual Fan Step X
A3 Outside air Temperature X
A4 Actual valid Room Temperature X
A5 Supply air Temperature X
A6 Exhaust air Temperature X
A7 Actual control Mode Temperature X
A8 Actual value controlled Temperature X
A9 Actual cooling setpoint X
A10 Actual heating setpoint X
A11 Actual supply cooling setpoint X
A12 Actual supply heating setpoint X
A13 Cooling output signal X
A14 Heatrecovery damper recovery value X
A15 Heatrecovery output signal X
A16 Heating output signal X
A17 Electrical heating output signal X
A18 Actual control Mode humidity X
A19 Actual value controlled humidity X
A20 Actual dehumidity setpoint X
A21 Actual humidity setpoint X
A22 Actual supply dehumidity setpoint X
A23 Actual supply humidity setpoint X
A24 Actual dehumidity value X
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 239

Siemens Climatix Series Specifications

General

Application	HVAC control
Communication Protocols	BACnet, Modbus, KNX
Inputs	Analog and digital inputs
Outputs	Analog and digital outputs
User Interface	web interface
Power Supply	24 V AC
Protection Class	IP20
Mounting	DIN rail mounting
