Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
17.15.32 Cooling 2 > Max limitation fan
Main Index > Unit > Temp control > Cooling 2 > Clg 2 max limit fan
Parameter Function Value range Unit Standard R S Link
Fan stage 0 Only visible if plant is not configured, not
used! Fix setted to 0
0…100 % 0 6
Fan stage 1 Max Output Value for Stage 1 0…100 % 100 6 Section:
Fan stage 2 Max Output Value for Stage 2 0…100 % 100 6
0
Fan stage 3 Max Output Value for Stage 3 0…100 % 100 6
17.15.33 Fan heating
Main Index > Unit > Temp control > Fan heating
Parameter Function Value range Unit Standard R S Link
Controller Actual Value Controller; Jumpline to settings 0…100 % X Section:
Deadzone Heating Deadzone for Fan compensation 0…20 °C 1.0 6
5.5.6
17.15.34 Fan cooling
Main Index > Unit > Temp control > Fan cooling
Parameter Function Value range Unit Standard R S Link
Controller Actual Value Controller; Jumpline to settings 0…100 % X Section:
Deadzone Cooling Deadzone for Fan compensation 0…20 °C 1.0 6
5.5.6
17.15.35 Fan compensation
Main Index > Unit > Temp control > Fan comp tmp
Parameter Function Value range Unit Standard R S Link
Controller Actual Value Controller; Jumpline to settings 0…100 % X
Setpoint Setpoint for the controller (related to the
actual Room or Exhaust Temperature)
0…99 °C 20.0 6 Section:
5.5.7
Function Defines If the speed of the Fans increases
or decreases if Setpoint is < than
Temperaure
Increase
Decrease
Increase 6
17.16 Humidity control
17.16.1 General
Main Index > Unit > Humidity control
Parameter Function Value range Unit Standard R S Link
Act controlled hum Actual Value of the controlled humidity %rH, g/kg X
Setpoints Jumpline to Humidity Setpoints X
Cascade controller Jumpline to settings for Cascade Controller
Actual Value humidification
Actual Value dehumidification
%rH, g/kg X
Max controller sply Jumpline to settings for Max humidification
controlling
X
Humidification Actual Value; Jumpline for Hunidification
settings
0…100 % X Section:
5.11.1
Dehumidification Actual Value; Jumpline to Dehumidification
controlller
0…100 % X
Fan compensation Actual Value; Jumpline for Fan
Compensation settings
0…100 % X
Summer disable Block the Humidification in Summer No
Yes
No 6
Dew point Calculated Dewpoint -64…64 °C X
Dewpoint deadzone Dew point Deadzone for contorlling -64…64 °C 6
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 206
