Siemens Climatix Series User Manual

209 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
17.18 Auxiliary
17.18.1 General
Main Index > Unit > Auxiliary
Parameter Function Value range Unit Standard R S Link
TSP Output Time Scheduler Output; Jumpline to settings Off
On
Off 6
Analog output Actual Value analog Output according to
active Fan Stage
0…100 % 0 6
A outp fan step 0 Output Value if Fan is Off (Default) 0…100 % 0 4
A outp fan step 1 Output Value if Fan Stage 1 (setpoint stage
1) active
0…100 % 0 4
A outp fan step 2 Output Value if Fan Stage 2 (setpoint stage
2) active
0…100 % 100 4
A outp fan step 3 Output Value if Fan Stage 3 (setpoint stage
3) active
0…100 % 100 4
Alarm input Alarm Input only for Alarming Passive
Active
X Chapter:
5.13.1
Input Digital Input only for display Off
On
X
Auxiliary tmp Temperature ony for display -64…64 °C X
Op mode output Output if the selected Operation Mode is
active
Off
On
x
Op mode outp select Operation Mode Selector (set the condition
when the Output is active according to the
acual state of the Unit)
Off
On/comfort
Economy.
Manual
Osstp
Night clg
UnOcc
Night kick
Fire dmper
Fire
Stop.
Heat
Hrec
Off 4
17.18.2 TSP output
Main Index > Unit > Auxiliary > TSP output
Parameter Function Value range Unit Standard R S Link
Output Time Scheduler Output Off
On
Off X
Manual operation Operation over HMI
NULL = no acces over HMI, TSP or BMS
could be active
Off and On = override from HMI
Off
On
NULL
NULL X
Chapter:
Schedule Jumpline to the Scheduler Off
On
On 4
5.13.2
Calendar exception Jumpline to the Calendar Passive
Active
4
From BACS Selection from where the Output is activated
Auto = TSP
Off and On = override from BMS
Auto
Off
On
Auto
17.19 Loop controllers
Main Index > Unit > Loop controllers
Parameter Function Value range Unit Standard R S Link
Supply fan Actual Value; Jumpline to Controller settings 0…100 % X
Exhaust fan Actual Value; Jumpline to Controller settings 0…100 % X
Air quality Actual Value; Jumpline to Controller settings 0…100 % X
Casc controller tmp Actual Value Heating/ Cooling; Jumpline to
Controller settings
0…100 % X
Min supply tmp Actual Value; Jumpline to Controller settings 0…100 % X
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 209
