Page #208 background imageLoading...
Page #208 background image
208 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
17.16.5 Humidification
Main Index > Unit > Humidity control > Humidification
Parameter Function Value range Unit Standard R S Link
Controller Actual Value Controller; Jumpline to settings 0…100 % X
Output signal Actual Output Signal; Jumpline to settings 0…100 % X
Command Humifiier status; Jumpline to settings On
Off
X
Feedback Humidifier Feedback; Jumpline to settings No Fdb
Ok
X
Section:
Pump. Pump Status; jumpline to Pump settings Off
On
4
5.11.5
Start up delay fdbk After this Time the Feedback has to be
TRUE
0…36000 --- S --- 10 6
Off by fdbk alarm In case of a Feedback Alarm the Pump is
switched Off
No
Yes
Yes 6
17.16.6 Humidification > Pump
Main Index > Unit > Humidity control > Humidification > Pump
Parameter Function Value range Unit Standard R S Link
Command Pump command On
Off
X
Feedback Pump Feedback NoFdbk
Fdbk
X
Alarm Pump Alarm Ok
Alarm
X Section:
5.11.6
Start up delay fdbk After this Time the Feedback has to be
TRUE
0...36000 --- S --- 6
Off by fdbk alarm In case of a Feedback Alarm the Pump is
switched Off
No
Yes
Yes 6
Min run time Mnimum On Time after a Start 0…36000 --- S --- 180 6
Kick date / time Pump Kick Date and Time 6 Section:
Kick interval Intervall Time for Pump Kick 0.0…36000.0 h 168.0 6
5.11.7
Kick on time Pulse length for Pump Kick 0…36000 --- S --- 60 6
17.16.7 Humidification > Fan compensation
Main Index > Unit > Humidity control > Humidification > HumFancomp
Parameter Function Value range Unit Standard R S Link
Controller Actual Value Controller; Jumpline to settings 0…100 % X
Setpoint Setpoint for the controller (related to the
actual Room Humidity)
0…100 % 50.0 6 Section:
5.11.8
Function Defines if the speed of the Fans increases
or decreases if Setpoint is < than Humidity
Increase
Decrease
Increase 6
17.17 Air qualtity control
Main Index > Unit > Air quality control
Parameter Function Value range Unit Standard R S Link
Controller Actual Value; Jumpline to Controller settings 0…100% X
Function Direction of the Output (0..100 or 100..0) Normal
Inverted
Normal 4 Section:
5.12
Setpoint Setpoint for the controller 0…3000 ppm 800 4
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 208
