213 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Time scheduler 01.02.2010
18 Time scheduler
18.1 Week schedulers
Main Index > Unit > Main overview > Time switch program > Schedule
Parameter Function Value range Unit Standard R S Link
Present
Value
Actual value from this this day 6
Monday Actual State from Monday if active; Jumpline to
Day Schedular Monday
6
Copy
schedule
Copy all entries from Monday to Tuesday up to
Friday
6
Tuesday Actual State from Tuesday if active; Jumpline to
Day Schedular Tuesday
6
... Actual State from …day if active; Jumpline to
Day Schedular …day
6 Section:
8.2
Saturday Actual State from Saturday if active; Jumpline to
Day Schedular Saturday
6
Sunday Actual State from Sunday if active; Jumpline to
Day Schedular Sunday
6
Exception Actual State from Exceptionday if active;
Jumpline to Day Schedular Excaptionday
6
Period:Start Only with PW level 2; Start Date when
Weekschedular is active (Default setting:always
active)
2 2
Period:Stop Only with PW level 2; Stop Date when
Weekschedular is passive
2 2
18.1.1 Day schedulers
Schedule > Day
Parameter Function Value range Unit Standard R S Link
Present
Value
Actual value from this this day 6
Day schedule Validity of the day 6
Time 1 Switching point 1 (allways 00:00) 00:00 6 Section:
Value 1
State 6
8.3
Time 2 ...
Time 6
Switching point 1 ... Switching poin 6 6
Value 2 ...
Value 6
6
18.1.2 Calendar (Exception, fix off)
Schedule > Calendar Exception / Calendar fix off
Parameter Function Value range Unit Standard R S Link
Present value Passive
Active
6
Choice-x Select the entry in the schedular
One day
A period from ... to
A special day
Entry not used
Date
Range
WeekDay
Passive
6
Section:
8.4
-(Start) date
6
-End date
6
-Week day
6
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 213
