Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
Main Index > Configuration > Configuration 2
Parameter Function Value range Unit Standard R S Link
Dehum tmp prio Dehumidification Control (tmpPrio= if
Heating > 90% DeHum is decreased)
No/Yes No 4
Dew point control Dew Point Control (only possible with Hum
Supply and Tmp Sply Sensor)
No/Yes No 4
Hum deviation alarm Alarm if the Humidification Setpoint is not
reached
Room or Exhaust Air is monitored
Supply Air is monitored
Supply and Room or Exhaust Air are
monitored
(only possible with a Room or/and a Supply
Sensor)
No
RoomExhaust
Supply
Sply+RmRtr
No 4
Humidifier pump Humidification Pump
Humidification Pump with Pump kick function
No
Yes
Yes+Kick
No
Hum pump alarm Alarming for Humidification Pump No
alarm
fdbk
both
No 4
Humidifier fdbk Generally Humidification Feedback No
Yes
No 4
Cooling pump Cooling Pump No
Yes
Yes+Kick
Yes+Kick 4
Cooling pump alarm Alarming for Cooling Pump No
alarm
fdbk
both
alarm 4
Coolng DX alarm Alarming for Dx Cooling No
alarm
fdbk
both
alarm 4
Htg 2 frost protect Heating 2 Frost function
Only Sensor
Sensor with 2 Setpoints
Only Detector
Sensor and Detector
Sensor with 2 Setpoints and Detector
No
sensor
Sensor2Spv
Detector
Snsr+Dtctr
2Spv+Dtctr
No 4
Heating 2 pump Heating 2 Pump
Heating pump with Pump kick function
No
Yes
Yes+Kick
Yes+Kick 4
Heating 2 pump alm Alarming for Heating 2 Pump No
alarm
fdbk
both
alarm 4 Section:
15.2
Heating 2 control Heating 2 Control
(In Sequence = additionally Heater eg.
ReHeater)
StandAlone/
InSequence
StandAlone 4
El heating 2 alarm Electrical heating 2 alarm No/Yes No 4
El Heating 2 control Electrical heating 2 Control
(In Sequence = additionally Heater eg.
ReHeater)
StandAlone/
InSequence
StandAlone 4
Cooling 2 pump Cooling 2 Pump No
Yes
Yes+Kick
Yes+Kick 4
Cooling 2 pump alm Alarming for Cooling 2 Pump No
alarm
fdbk
both
alarm 4
Cooling 2 Dx alarm Alarming for Dx Cooling 2 No
alarm
fdbk
both
No 4
Cooling 2 control Cooling 2 Control
(In Sequence = additionally Cooler
StandAlone/
InSequence
StandAlone 4
Fire damper fdbk Fire damper Feedback signals
Only one fdbk for Closed
Two fdbk’s opened and closed
One fdbk signalise opened and closed (
1=>0=>1 = closed => move => opened)
Clsd
Clsd+Opnd
Combined
Clsd 4
Auxiliary input Auxiliary input Function
Input = Auxiliary input only for Display
alarm = Input for alarm
Inp+Alm = 2 Auxiliarx Inputs one for Display
one for alarm
No
Input
alarm
Inp+Alm
No 4
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 183
