Page #234 background imageLoading...
Page #234 background image
234 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Appendices 01.02.2010
Name Type Position
(IO
Check)
Name Type Position
(IO
Check)
Supply damper (combined) DO 131 DX cooling output 1 DO 150
Exhaust damper DO 132 DX cooling output 2 DO 151
Fire damper DO 133 Extra electrical heater output 1 DO 152
Supplyfan output 1 DO 136 Extra electrical heater output 2 DO 153
Supplyfan output 2 DO 137 Pump Extra heating DO 154
Supplyfan output 3 DO 138 Pump Extra cooling DO 155
Exhaustfan output 1 DO 139 DX cooling extra cooler output 1 DO 156
Exhaustfan output 2 DO 140 DX cooling Extra cooler output 2 DO 157
Exhaustfan output 3 DO 141 Aux time switch program DO 165
Electrical heater output 1 DO 145 Aux operation mode indication DO 166
Electrical heater output 2 DO 146 Alarm output High/A (combined) DO 168
Pump heater DO 147 Alarm output Low/B DO 169
Pump/Manoeuvre recovery DO 148 Humidifier DO 171
Pump cooler DO 149 Pump humidity DO 172
Digital outputs
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 234
