Siemens Climatix Series User Manual

129 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Communication 01.02.2010
Main Index > System overview > Communication > Comm module overview >
Module[x] BACnet IP
Parameter Range Function
State − OK.
− Alarm
Module state.
Comm failure − Passive
− Active
Communication error between module and con-
troller.
BACnet:
Device name. Controller name on the network.
Device ID. Controller address on the network.
Port Communication port on the network.
BACnet Setting Go to parameter page for BACnet settings.
TCP/IP:
DHCP
− Active
− Passive
Displays type of address assignment:
− DHCP server issues addresses.
− IP address is fixed.
WINS name Displays module name.
IP Displays controller IP address.
Mask Displays subnet mask.
Gateway Displays gateway address.
TCP/IP settings Go to parameter page for TCP/IP settings.
General:
Software version Module software version.
Device ID. Module internal device ID.
Modules Module type.
Diagnostics. Displays module hardware and software version.
Use default − Passive
− Active
Resets all BACnet IP parameters to standard
module values at delivery.
Reset required !!
− 
− Execute
(Display only) As a matter of principle, the con-
troller must be set after parameterization to as-
sume the data (on the "Comm module overview"
page).
Main Index > System overview > Communication > Comm module overview >
Module[x] BACnet IP > BACnet settings
Parameter Range Function
Device name Change BACnet device name. Must be unique
for each network.
Device ID. Change BACnet device ID. Must be unique for
each network.
Port 47808…47823 Settings for the communications port.
Imperial unit sys
−
Changes unit from metric system to imperial.
− Metric.
− Imperial.
Unicode − Passive
− Active
Character set for description language. The
standard ASCII character set is used.
Only required for languages such as Chinese or
Russian (these languages are not yet imple-
mented).
Parameter
BACnet parameteriza-
tion
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 129
