153 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Configuration 01.02.2010
Enter password for level 4:
Select Start page, enter password --->
Select Main Index page, Configuration --->
Configuration page
The configuration page includes the following lines and associated parameters:
Line Parameter Explanation
Configuration by Select configuration type.
Download You can download a preconfigured plant using the Saphir Scope
tool or from a SD card.
You must reset the controller after the download.
In this mode, all objects in Saphir Scope Tool and line in HMI are
visible.
HMI Config
The plant is configured in stages using the operator unit.
Requirement: List of all I/Os. It displays the available I/O's and the
I/O position they are suppose to occupy.
You also need the sensor type for sensors.
This is the normal mode that must be selected to start the plant.
Caution: You cannot change over from HMI Config to
download while the plant is running. This would immediately
shut down all outputs and reset the controller!
Configuration 1 NotDone
Done
Link to Configuration 1 page and displays whether or not parame-
terization of Configuration 1 was completed.
Configuration 2 NotDone
Done
Link to Configuration 2 page and displays whether or not parame-
terization of Configuration 2 was completed.
Configuration IO’s NotDone
Done
Link to Configuration I/Os page and displays whether or not
parameterization of Configuration I/Os was completed.
Check Config IO’s To Check Config I/Os page.
Doubled Fault
OK.
Displays whether an input or output can be used multiple times.
Fault generates an alarm that locks the plant.
Not Configured Fault
OK.
Displays whether a function is enabled and the required I/Os are
not assigned. Fault generates an alarm that locks the plant.
The plant cannot be starting without Configuration By=HMI config and
Configuration 1=Done, Configuration 2=Done, Configuration IO’s=Done.
Preparation
Content of configuration
page
Note
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 153
