Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
17.8.5 Digital alarms
Main Index > Configuration > Configuration IO’s > IO conf alarms
Parameter Function Value range Unit Standard R S Link
Htg frost monitor IO Position Heating frost monitor NUsd,Comm,X1…X28 NUsd 4
Heating pump IO Position Heating pump alarm NUsd,Comm,X1…X28 NUsd 4
Heating pump fdbk IO Position Heating pump Feedback NUsd,Comm,X1…X28 NUsd 4
Electrical heating IO Position Electrical Heater alarm NUsd,Comm,X1…X28 NUsd 4
Hrec frost monitor IO Position Heat recovery frost monitor NUsd,Comm,X1…X28 NUsd 4
Hrec (pump)/cmd IO Position Heat recovery pump alarm NUsd,Comm,X1…X28 NUsd 4
Hrec pump fdbk IO Position Heat recovery pump Feedback NUsd,Comm,X1…X28 NUsd 4
Heat recovery IO Position Heat recovery alarm NUsd,Comm,X1…X28 NUsd 4
Cooling pump IO Position Cooling pump alarm NUsd,Comm,X1…X28 NUsd 4
Cooling pump fdbk IO Position Cooling Pump Feedback NUsd,Comm,X1…X28 NUsd 4
Cooling Dx IO Position Dx Cooling alarm NUsd,Comm,X1…X28 NUsd 4
Cooling Dx fdbk IO Position Dx Cooling Feedback NUsd,Comm,X1…X28 NUsd 4
Humidifier pump IO Position Humidification Pump alarm NUsd,Comm,X1…X28 NUsd 4
Hum pump fdbk IO Position Humidification Pump Feedback NUsd,Comm,X1…X28 NUsd 4
Humidifier fdbk IO Position Humidification Feedback NUsd,Comm,X1…X28 NUsd 4
Htg 2 frost monitor IO Position Heating 2 frost monitor NUsd,Comm,X1…X28 NUsd 4
Heating 2 pump IO Position Heating 2 pump alarm NUsd,Comm,X1…X28 NUsd 4
Htg 2 pump fdbk IO Position Heating 2 pump Feedback NUsd,Comm,X1…X28 NUsd 4 Section:
El Heating 2 IO Position Electrical Heater 2 alarm NUsd,Comm,X1…X28 NUsd 4
0
Cooling 2 pump IO Position Cooling 2 pump alarm NUsd,Comm,X1…X28 NUsd 4
Cooling 2 pump fdbk IO Position Cooling 2 Pump Feedback NUsd,Comm,X1…X28 NUsd 4
Cooling 2 Dx IO Position Dx Cooling 2 alarm NUsd,Comm,X1…X28 NUsd 4
Cooling 2 Dx fdbk IO Position Dx Cooling 2 Feedback NUsd,Comm,X1…X28 NUsd 4
Fan IO Position Fan alarm (only if combined
Fan)
NUsd,Comm,X1…X28 NUsd 4
Supply fan IO Position Supply fan alarm NUsd,Comm,X1…X28 NUsd 4
Exhaust fan IO Position Exhaust fan alarm NUsd,Comm,X1…X28 NUsd 4
Supply fan fdbk IO Position Supply fan Feedback (eg.
Pressure switch)
NUsd,Comm,X1…X28 NUsd 4
Exhaust fan fdbk IO Position Exhaust fan Feedback (eg.
Pressure switch)
NUsd,Comm,X1…X28 NUsd 4
Filter IO Position Filter alarm (only if combined
Fan)
NUsd,Comm,X1…X28 NUsd 4
Supply filter IO Position Supply filter alarm NUsd,Comm,X1…X28 NUsd 4
Exhaust filter IO Position Exhaust filter alarm NUsd,Comm,X1…X28 NUsd 4
Fire IO Position Fire alarm NUsd,Comm,X1…X28 NUsd 4
Outs air damper fdbk IO Position Outside air damper Feedback NUsd,Comm,X1…X28 NUsd 4
Extr air damper fdbk IO Position Extract air damper Feedback NUsd,Comm,X1…X28 NUsd 4
Fire damper Closed IO Position Fire damper Feedback closed NUsd,Comm,X1…X28 NUsd 4
Fire damper Opened IO Position Fire damper Feedback opened NUsd,Comm,X1…X28 NUsd 4
Auxiliary IO Position Auxiliary alarm NUsd,Comm,X1…X28 NUsd
17.8.6 Other
Main Index > Configuration > Configuration IO’s > Other
Parameter Function Value range Unit Standard R S Link
Air quality Sensor
Pos IO Position NUsd,Comm,X1…X28 NUsd 4 Section:
Y1 Humidity Sensor curve Value for 0V 0...3000 ppm 2000 4
15.3.7
External setpoint IO Position External setpoint
Pos IO Position NUsd,Comm,X1…X28 NUsd 4
17.8.7 Outputs damper
Main Index > Configuration > Configuration IO’s > IO conf damper outp
Parameter Function Value range Unit Standard R S Link
Outs air damper DO IO Position Output Outside air damper NUsd,Comm,DO1...DO
24
NUsd 4 Section:
Extr air damper DO IO Position Output Extract air damper NUsd,Comm,DO1...DO
24
NUsd 4
15.3.8
Fire damper DO IO Position Output Fire damper NUsd,Comm,DO1...DO
24
NUsd 4
