Siemens Climatix Series User Manual

192 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies HMI 01.02.2010
17.12.2 Time switch program
Main Index > Unit > Operating mode >Time switch program
Parameter Function Value range Unit Standard R S Link
Schedule Only if TspFunction <= Steps
Jumpline to the Scheduler
Off
Stage1…Stage3
Off X
Schedule Only if TspFunction = Steps+Tmp
Jumpline to the Scheduler
Off
Eco St1…Eco St3
Comf St1…Comf St3
Off X Section:
5.2.3
Calendar exception Jumpline to the Calendar Passive…Active X
Calendar fix off Jumpline to the Calendar Off (special
settings in Exceptions)
Passive…Active X
17.12.3 External control
Main Index > Unit > Operating mode > External control
Parameter Function Value range Unit Standard R S Link
Act mode Actual Operating Mode from External
Control
Auto = TSP
Off and Stage 1 ..Stage 3 = override from
External Unit Switch
Auto
Off
Stage1…Stage3
X
Tmp stpt input 1 Only possible if TSP Function= Step+Temp
Start the Unit in selected Mode
Only Input 1 Enabled
Start the Unit in selected Mode with setted
Fan Step
Input 1 and 2 Enabled
if Input 1 = TRUE Start the Unit in selected
Mode with Fan Step 1
if Input 2 = TRUE Start the Unit in selected
Mode with Fan Step 2
if both Inputs are TRUE Start the Unit in
selected Mode for Input 2 with setted Fan
Step
Comfort
Economy.
Comfort 4
Tmp stpt input 2 Only possible if TSP Function= Step+Temp
and External Control = Two
if Input 2 = TRUE Start the Unit in selected
Mode with Fan Step 2
if both Inputs are TRUE Start the Unit in
selected Mode for Input 2 with setted Fan
Step
Comfort
Economy.
Comfort 4 Section:
5.2.4
Off delay After this Time the External Control is
disabled.
If this Time is 0 the Timer function is
disabled
0…23 h 0.0 4
Fan steps The selection of the Step and Operation
TSP Function= Step
Only Input 1 Enabled
Input1=TRUE  selected Fan Step
Input1 = False  Auto
Two Inputs Enabled
Input1 = TRUE Step1
Input2 = TRUE Step2 (only one Step
enabled St1)
Input1 and Input2 = TRUE selected Fan
Step
Input1 and Input2 = FASLE  Auto
Auto
Off
1Step
2Step
3Step
4
Start/Stop Funct Activate the Pushbutton function for the
Inputs 1 and 2
Off
On
Off 4
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 192
