92 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Functions 01.02.2010
Parameter Range Function
Op mode output – Off
– On
Displays whether the desired (using Op mode outp
select) operating mode for the plant is enabled. Go
to page with digital output settings.
Op mode outp select
– Off
– On/Comfort
– Economy
– Manual
– Osstp
– Night clg
– Unocc
– Night kick
– Fire dmper
– Fire
– Stop
– Running
– Htg full
– Hrec full
– Clg full
Selection of operating modes to be displayed on
output op mode output:
– Plant off.
– Plant on or in Comfort mode.
– Plant in Economy mode.
– Manual intervention enabled.
– Boost enabled.
– Night cooling, active.
– Not used, active (Temp. difference start).
– Plant kick enabled.
– Fire damper test enabled.
– Fire alarm enabled; plant in fire alarm mode.
– Plant stopped and locked.
– Plant is operating (On/Co/Ec/Osstp/
NightClg/Unocc/Nightkick/Startup).
– Hot water or electrical register on
100 %.
– Heat recovery (plates, water, heat wheel) at
100%.
– Cooling at 100 %.
5.13.2 TSP output
Main Index > Unit > Auxiliary > TSP output
Parameter Range Function
Output – Off
– On
Present state for output. Go to page with digital out-
put settings.
Manual operation
– Off
– On
– NULL
Manual adjustment of output (always has the high-
est priority).
– Off.
– On.
– Auto: The time switch catalog or the BACS con-
trols the output.
Schedule – Off
– On
Present value for the time switch program. Go to
page with time switch program settings.
Calendar exception
– Passive
– Active
Present status of calendar for exception days. Go to
page with calendar settings.
– Calendar not in intervention.
– Calendar in intervention.
From BACS
– Auto
–
– Off
– On
Control output via BACS:
– No intervention by BACS: The time switch cata-
log only acts on the output in this position.
– Off from BACS.
– On from BACS.
Parameter
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 92
To Next Page
