Siemens Climatix Series User Manual

96 / 244
Siemens Standard application AHU CE1P3977en_02
Building Technologies Detail pages: Inputs and outputs 01.02.2010
Parameter Range Function
Reliability – OK.
– Other
– Process Error
– Config err
Reliability state for hardware.
– Basis controller: Calibration lacking (output defec-
tive). Extension module POL955: Calibration lack-
ing (Output defect) or communication to base con-
troller unavailable or the output is incorrectly con-
figured.
– Basis controller: Process error in program.
– Extension module: Message no available.
– Basis Controller: Output configured incorrectly.
Extension module: Message no available.
Active prio – Out of serv.
– Prio1
– ….
– Prio16
– Default
Displays the wired Prio elements currently on the
output.
Special settings --- Go to Special settings page (at access levels 4 and
2 only).
Special infos --- Go to Special info page (at access levels 6, 4 and 2
only).
Priority array --- Go to Priority array page (at access levels 6, 4 and
2 only).
6.2.2 Special settings
• Read: Levels 4 and 2.
• Write: Levels 4 and 2.
Parameter Range Function
Msg class fault
– Danger (A)
– High (A)
– Low (B)
– Warning (C)
– No alarm
Set alarm class (and groups A, B, C):
– Set the Unit in Stop Mode.
– Set the Unit in Off Mode.
– Only Message.
– Only Message.
– No Message, no Alarm.
High limit 0…100 [%] Upper limit of output signal.
Low limit 0…100 [%] Lower limit of output signal.
Access level
Parameter
Basis Document Siemens Climatix Control System
BDCX.100820.01GB
Page 96
