Changeover from STRUC V4.x to D7-SYS
System- and communication configuring D7-SYS - SIMADYN D 4-3
Edition 03.2001
Data type Byte Double word
Extension *_BY *_DW
Table 4-2 Exceptions of data type extensions
4.1.2 Control blocks
STRUC
V.4.x
CFC with
D7-SYS
Pre-
assignment
*(‘---‘ = 0)
Comment
Control blocks
PT10F1 PT1 ---
With setting function; new inputs SV,
S; function: Yn+1=SV for S=1
DT10F DT1 --- With setting function; new inputs SV,
S; function: Yn+1=SV for S=1
DIF0F DIF --- ---
PC_3F PC
QU = 1;
QL = 1;
---
INT0F INT --- ---
PIC2F PIC
QU = 1;
QL = 1;
---
LIM0F LIM
QU = 1;
QL = 1;
---
DEZ0F DEZ --- ---
DEL0F DEL --- ---
RGE0F RGE --- ---
RGJ0F1 RGJ --- ---
PMW0F PMW --- ---
FUZ001 FUZ_I --- X1..10 as "INT" (previously "N2");
Y1..4 as "INT" (previously "N2")
FUZ01F FUZ --- ---
PT10F --- --- Eliminated; replaced by PT1
STC0F --- --- Eliminated; not replaced
* Corresponds to „0“ as pre-assignment of the various parameters of the
individual function blocks.
Table 4-3 Changes in the control blocks
