Changeover from STRUC V4.x to D7-SYS
4-4 System- and communication configuring D7-SYS - SIMADYN D
Edition 03.2001
4.1.3 Arithmetic blocks
STRUC
V.4.x
CFC with
D7-SYS
Pre-
assignment
*(‘---‘ = 0)
Comment
Arithmetic blocks
ADD2F - --- Eliminated; replaced by ADD
- ADD --- New; generic at the input side
ADD4F - --- Eliminated; replaced by ADD
ADD8F - --- Eliminated; replaced by ADD
ADDI - --- Eliminated; replaced by ADD_I
- ADD_I --- New; generic at the input side
ADDI4 - --- Eliminated; not replaced
SUB0F SUB --- ---
SUBI SUB_I --- ---
MUL0F - --- Eliminated; replaced by MUL
- MUL --- New; generic at the input side
MULI - --- Eliminated; replaced by MUL_I
- MUL_I --- New; generic at the input side
MULI4 - --- Eliminated; not replaced
DIV0F - --- Eliminated
DIV0F1 DIV X2 = 1 ---
DIVI DIV_I X2 = 1 ---
SQR0F SQR --- ---
SII0F SII --- ---
AVA0F AVA --- ---
MAS0F - --- Eliminated; replaced by MAS
- MAS --- New; generic at the input side
MIS0F - --- Eliminated; replaced by MIS
- MIS --- New; generic at the input side
PLI6F PLI10 --- 10 instead of previously 6 points
PLI2F PLI20 --- ---
SIN0F SIN --- ---
ASINF ASIN --- ---
COS0F COS Y = 1 ---
ACOSF ACOS
Y = π/2
---
TAN0F TAN --- ---
ATANF ATAN --- ---
* Corresponds to „0“ as pre-assignment of the various parameters of the
individual function blocks.
Table 4-4 Change in the arithmetic blocks
