Siemens SIMADYN D User Manual

Closed-loop thyristor current control
System- and communication configuring D7-SYS - SIMADYN D 5-81
Edition 06.2002
5.8.2 Standard connections
Connec-
tion
Type Significance Source
PA6.ZPA
ON NV Firing pulse number PC6.ZPA
PC6.CTH
ON NV Firing pulse output, time value PA6.CTH
PC6.CTS
ON NV Time value, start of FB PA6 PA6.CTS
PC6.EN
ON
NV Enable firing angle controller PA6.RDY
PC6.X6R
ON
NV
Numerical
=
ˆ
60° of the line supply periods [16 MHz]
PA6.Y6R
PC6.XAS
ON NV Firing angle actual value [ASG] PA6.XAS
PC6.WAS
ON
SP Firing angle setpoint [ASG] CPI.Y
PC6.ICC
ON
NV Control word SOL.QCC
PC6.ACI
ON
NV Handshake from the CAV block CAV.ACO
EMF.XC ON SP Current actual value (with sign) CAV.YC
EMF.ACI
ON NV Handshake from the PC6 block PC6.ACO
SOL.ION ON SP On command of the closed-loop thyristor current control (,FCS
present)
FCS.QON
SOL.DZM
ON
NV Operating signal, double firing PC6.DZM
SOL.XC
ON
NV Current actual value (with sign) CAV.YC
SOL.XEV
ON
NV EMF value calculated EMF.YEV
SOL.QSC
ON NV Fault word from CAV CAV.QSF
SOL.QSM
ON NV Fault word from EMF EMF.QSF
SOL.QSA
ON NV Fault word from PA6 PA6.QSF
SOL.QSP
ON
NV Fault word from PC6 PC6.QSF
SOL.QSS
ON
NV Fault word from FCS (, if programmed) FCS.QSF
CAV.IM1
ON
NV
Torque direction M1 operational
⇒ “+” = CX1
SOL.Q01
CAV.IM2
ON
NV
Torque direction M2 operational
⇒ “-” = CX2
SOL.Q02
CAV.ACI
ON
NV Handshake from the EMF block EMF.ACO
CPC.WC
ON
NV Current setpoint (absolute value) CSP.YWC
CSP.WC ON SP Current setpoint from the switch-over logic stage SOL.YWC
CPI.WC ON SP Current setpoint (absolute value) CSP.YWC
CPI.XC
ON NV Current actual value (with sign) CAV.YC
CPI.SV
ON
NV Setting value, integrator from the switch-over logic stage SOL.YSV
CPI.S
ON
NV Setting the integrator with value SV SOL.QCS
CPI.EN
ON
NV Controller enable SOL.QCE
CPI.ILU
ON NV Inhibits the integrator, positive direction CSP.QIU
CPI. ILL
ON NV Inhibits the integrator, negative direction CSP.QIL
NV=Connection required
SP=Standard connection according to the standard configuring
