Siemens SIMADYN D User Manual

Communications configuring
3-128 System- and communication configuring D7-SYS - SIMADYN D
Edition 12.2003
3.8.3 Configuring example, service to CFC
• A CS7 communications module with SS4 communications module
must be available in the subrack.
• All of the subrack CPUs can be addressed from the CFC via
CS7/SS4.
• Service utility and DUST1 central block coupling on CPU 3 (slot 6).
NOTE
CFC online addresses the CPU via the slot number (address stage 1 at
input US=slot number 6)
Righthand margin
Lefthand margin
ECL
ECO
CDM
QTS
-
-
-
-
-
-
-
CTS
BDR
TWU
CDV
@CSD01
'SER3.06'
240
19200
10
0
D04CS7.X02
D04CS7.X02
SER
QTS
YTS
-
-
-
-
-
CTS
US
LT
Fig. 3-41 DUST1 with service
3.8.4 Configuring example, process data between SIMADYN D
subracks
• A CS7 communications module with SS4 communications module
must be available in both subracks.
• Only the transmit- and receive blocks of the communications utility,
process data, can be used for data transfer between the CPUs of
various subracks via DUST1.
3.8.4.1 Subrack 1
The DUST1 central coupling block and 1 transmit- and 1 receive block
are configured on CPU 4 of subrack 1.
Description
Description
Description
