Changeover from STRUC V4.x to D7-SYS
System- and communication configuring D7-SYS - SIMADYN D 4-33
Edition 03.2001
4.7 V4.x terminology which is replaced by D7-SYS terminology
Terms, which were used in the SIMADYN D environment for Version 4.x
are compared in this list, with D7-SYS.
The appropriate explanations can be taken from the glossary.
Terminology from Version
4.x
Comparable/new terms Comment
Connector Function block output
Output
CAUTION, previously in SIMADYN D up to V4.x
"Connector" was used which is now designated
"connection" (I/O).
Interrupt task Interrupt task
EEPROM Change memory
PSW User program
Module Module
Board ID Module name
Rack Subrack
Rack Subrack
Output connector Function block output
Output
Input connector Function block input
Input
Initialization, run-up INIT mode
Cyclic operation RUN mode
Processor board, processor CPU module
Processor number CPU number
Daisy chain connector Daisy chain jumper
Connector type Data type
Dialog box Dialog box
Signal module I/O module
Dimensions Units, units text
Configuring mode Create mode
Message system reference Name reference
Promming, loading into the
memory module
Offline loading
Download Online loading Loading in the CPU module, loading via a
communications link
Configuring, programming Configuring
Interrupt event Process interrupt
SIMADYN D program Chart container Contrary to an S7- or M7 program, a
SIMADYN D program only has a chart container.
Basic dialog SIMATIC Manager
Scaling value Scaling factor
Memory-Card, Memory module
Memory sub-module Memory module
