Communications configuring
3-236 System- and communication configuring D7-SYS - SIMADYN D
Edition 12.2003
93,75 1 12 34
22 264
25 300
19,2 1 30 135
6 180
10 300
9,6 1 52 240
6 312
Table 3-73 Bus circulating time
NOTE
A configured station which still is not available on the USS bus extends
the bus circulating time by 20 milliseconds.
If an OP2 is powered-up, then to start off with, the descriptive data of the
configured process data and binary values from SIMADYN D are
transferred to the OP2. The maximum time for this initialization is, for a
bus circulation time of 300 milliseconds, approximately 40 seconds.
3.20.5 Configuring example
The example describes an "OP2SYS" display system with three operator
control devices. The three operator control devices have the station
addresses 0, 8 and 22 at the USS bus.
Only the function blocks relevant for OP2 are listed here. It is also
necessary, for example, to configure a @CSU.
