Changeover from STRUC V4.x to D7-SYS
System- and communication configuring D7-SYS - SIMADYN D 4-13
Edition 03.2001
4.1.7 Conversion blocks
STRUC
V. 4.x
CFC with
D7-SYS
Pre-
assignment
*(‘---‘ = 0)
Comment
Conversion blocks
BSC B_W --- ---
SBC W_B --- ---
SBW BY_W --- ---
SWB W_BY --- ---
I2NF I_R --- ---
NFI2 R_I --- ---
WDC I_D --- X as "INT (previously "N2");
Y as "DINT (previously ("N4")
DWC04 D_I --- X as "DINT (previously "N4");
Y as "INT" (previously "N2")
DWR04 - --- Eliminated; not replaced
DWS04 - --- Eliminated; not replaced
N2NF - --- Eliminated; not replaced
N4NF - --- Eliminated; not replaced
NFN2 - --- Eliminated; not replaced
NFN4 - --- Eliminated; not replaced
CBR SWB_W --- ---
CBR04 SWB_DW --- ---
CBRIF SWBI --- ---
CBRQF SWBO --- ---
BNR0F BNR
STZ = 2;
NF = 1;
---
I4NF D_R --- ---
NFI4 R_D --- ---
* Corresponds to „0“ as pre-assignment of the various parameters of the
individual function blocks.
Table 4-9 Changes in the conversion blocks
