Siemens SIMADYN D - Overview of the Communication Utilities

Communications configuring
3-8 System- and communication configuring D7-SYS - SIMADYN D
Edition 12.2003
Used for the
communications
partner
• SIMOVERT, SIMOREG drive converters
• OP2 operator control devices
• VD1 numerical display
Hardware required
• Master: CS7 communications module with SS4
communications module
Communications
utility
• Process data
• Parameter processing
• Message system
• Display
Central coupling
block
• @CSU
Features
• Single-master bus for communications between
SIMADYN D (master) with a maximum of 31
communication partners
• Master-slave principle (CS7/SS4 is the master)
• 9,6, 19,2, 38,4, 93,75 or 187,5 kbaud
• For drive converters: Maximum net data length is
28 bytes
Table 3-11 USS master coupling
Used for the
communications
partner
• CFC
• WinCC
• SIMATIC-OPs
Hardware required
• CS7 communications module with SS52
communications module
Communications
utility
• Service
• S7 communications
Central coupling
block
• @CSMPI
Features
• Multi-master bus with a maximum of 126 nodes
• 187,5 kbaud
• Standard for SIMATIC S7
Table 3-12 MPI coupling
3.1.2 Overview of the communication utilities
Various data can be transferred via the communication interfaces, for
example, process data and messages.
The communication utilities define which information/data is to be
transferred. The communication utilities are defined by configuring the
communication modules.
USS master
MPI
General
