Wiring
5-13
Distributed I/O Device ET 200M
EWA-4NEB780600602-06
5.2 Wiring
In This Chapter
Section Subject Page
5.2.1 Wiring Rules 5-13
5.2.2 Wiring the Power Supply Module and IM 153-x 5-15
5.2.3 Wiring the Front Connectors of the Signal Modules 5-17
5.2.4 Connecting Shielded Cables via a Shield Contact Element 5-21
5.2.1 Wiring Rules
Note: The cables for the front connectors should be longer in a configuration for
”module change during operation” (see Section 5.2.3).
Table 5-2 Wiring rules for the power supply and the IM 153-x
Wiring Rules for ...
Power Supply and IMWiring Rules for ... Power Supply and IM
153-x
Connectable wire cross-sections for rigid lines No
Connectable wire Without wire end ferrule 0.25 to 2.5 mm
2
cross-sections for flexible
lines
With wire end ferrule 0.25 to 1.5 mm
2
Number of wires per connection 1 or a combination of 2 wires
up to 1.5 mm
2
(sum) in a
common wire end ferrule
Maximum external diameter of the wire’s insulation ∅ 3.8 mm
Stripping length of the wires Without insulating collar 11 mm
With insulating collar 11 mm
Wire end ferrules to Without insulating collar Form A 10 to 12 mm long
DIN 46228
With insulating collar Form E, up to 12 mm long
