8.3 Technical Specifications
General Technical Specifications
In the Module Specifications Reference Manual you can find the following for the
IM 153-x:
General technical specifications that are valid for the S7-300 and ET 200M
system.
Deviating technical specifications and tests for the IM 153-1 for the extended
range of environmental conditions (”outdoor”) (order number
6ES7 153-1AA8x-0XB0).
Technical Specifications of the IM 153
The following table contains the technical specifications for all the functions of the
different IM 153-x versions. Check using Table 1-2 on page 1-9 the version as of
which your IM 153-x offers this function.
Technical Specifications IM 153-1 IM 153-2 IM 153-2 F0
Manufacturer ID 801D
H
801E
H
8071
H
Device master file
for DPV1
SIEM801D.GSD
SI01801D.GSG
SIEM801E.GSD
SI01801E.GSG
(for IM 153-2AA0x)
SI02801E.GSG
(for IM 153-2BA0x)
SIEM8071.GSD
SI018071.GSG
(for IM 153-2AB0x)
SI028071.GSG
(for IM 153-2BB0x)
Dimensions and Weight
Dimensions W H D (mm) 40 125 117
Weight 360 g
PROFIBUS-DP interface
Baud rates Up to 12 Mbaud 9.6; 19.2; 45.45
93.75; 187.5;
500 kbaud;
1.5; 12 Mbaud
Baud rate detection Yes Yes Yes
Interface RS 485 FO
FREEZE compatibility Yes
SYNC compatibility Yes
PROFIBUS addresses 1 to 125 permissible
Configuration modification in
RUN
No Yes Yes
