Configuration Options with the ET 200M
3-2
Distributed I/O Device ET 200M
EWA-4NEB780600602-06
3.1 Distributed I/Os with the IM 153-1
The IM 153-1 is the slave interface module of the ET 200M for standard
applications.
Figure 3-1 shows an example of an ET 200M with an IM 153-1 and 4 I/O modules
of the S7-300 as distributed I/Os on a CPU 315-2 DP as S7-DP master.
CPU 315-2 DP as DP master
IM 153-1
PROFIBUS
Figure 3-1 Distributed I/Os with the IM 153-1
