Siemens SIMATIC ET 200M

Technical Specifications
8-7
Distributed I/O Device ET 200M
EWA-4NEB780600602-06
8.2 Parameters of the IM 153-x
Parameter Assignment
Assign parameters to the IM 153-x and the ET 200M with STEP 7 or
COM PROFIBUS. If you use another configuration tool, you must integrate the
device master file.
Table 8-2 Parameters of the IM 153-x
Parameters
Value Range Default Applicability
DPV1 mode Disable/enable Enable ET 200M
Startup if preset
configuration0actual
configuration?
Yes/no No ET 200M
”Module change
during operation”?
Yes/no No ET 200M
Diagnostic interrupt Disable/enable Enable ET 200M
Process interrupt Disable/enable Enable ET 200M
Removal and insertion
interrupts
Disable/enable Enable ET 200M
Analog-value format SIMATIC S 7/
SIMATIC S 5
SIMATIC S7 ET 200M
Enhanced diagnostics Yes/no No ET 200M
Configuration:
see Section 6.4.1
No: 29 bytes;
Yes: 64 bytes in the case
of the IM 153-1 and 96
bytes in the case of the
IM 153-2 diagnostic frame
Module diagnosis Disable/enable Enable ET 200M
Module status Disable/enable Enable ET 200M
Channel-specific
diagnosis
Disable/enable Enable ET 200M
