Siemens SIMATIC ET 200M Manual

Wiring
5-11
Distributed I/O Device ET 200M
EWA-4NEB780600602-06
Configuration with Isolated Modules
Figure 5-4 shows the potentials of an ET 200M configuration with isolated
input/output modules.
N
M
L1
L +
M
PS IM 153-x
mP
L1
N
24V DC load current supply
M
ext
L +
U
int
M
int
Data
L1
N
DE DA
PI
230V AC load
current supply
Ground bus in cabinet
Figure 5-4 Simplified illustration of the configuration with isolated modules
