Procedure for Parameterizing Clock Synchronism
1. Settings at the CPU:
”Object Properties” of the CPU > ”Clock-Synchronized Interrupts” tab
– Set CPU clock-synchronized interrupt.
– Select the used DP master system.
– Select the desired subprocess image.
– Recommended delay time:
Accept the default setting.
Memory Interrupts Time Interrupts Cyclic Interrupts Diagnostics / Clock
General Startup Clock-Synchr. Interrupts Cycle / Clock Flag Remanence
OB 61:
Priority
DP Master
System No.
Subprocess Image(s)
(e.g.: 1.4)
Time Delay
1 1 ms
Default
3.000
25
25
Protection
Figure 3-7 ”Clock-synchronized interrupts” dialog box
