Product Overview
1-3
Distributed I/O Device ET 200M
EWA-4NEB780600602-06
Structure of a PROFIBUS-DP Network
The figure below shows you a typical PROFIBUS-DP network configuration. The
DP masters are integrated in the relevant device – for example, the S7-400 has a
PROFIBUS-DP interface, and the IM 308-C master interface module is inserted in
the S5-115U. The DP slaves are the distributed I/O devices connected to the DP
masters via PROFIBUS-DP.
DP master
DP slaves
PROFIBUS-DP
S7-400
PG/PC
ET 200L ET 200M
S5-95U-DP
Other field devices
with IM 308-C
S5-115U
ET 200X
OP/OS
S7-200Drive
DP/AS-I LINK
ET 200S
Figure 1-1 Typical PROFIBUS-DP network structure
