Commissioning and Diagnostics
6-27
Distributed I/O Device ET 200M
EWA-4NEB780600602-06
Table 6-13 Channel-specific error messages – manufacturer-specific
Error Type
Error Text Meaning What to Do
10000
B
16
D
Parameter
assignment
error
Parameter assignment error, for example, because:
The module cannot use the parameter
(unknown, impermissible combination...)
Module is not parameterized
Correct the
parameter
assignment
10001
B
17
D
Sensor or
load voltage
missing
The following voltage may be missing:
External supply voltage
Voltage to operate the module
Correct the
process wiring.
10010
B
18
D
Fuse defect Failure of fuse that can be replaced by the user Replace the fuse.
10100
B
20
D
Ground fault Ground fault, for example:
Permissible common-mode voltage in the case
of non-isolated channels exceeded
M cable in the case of isolated channels ripped
Correct the
process wiring.
10101
B
21
D
Reference
channel error
Error on the reference channel Replace reference
channel module
10110
B
22
D
Process
interrupt lost
Process interrupt is lost Correct the
program/process/
module match
11001
B
25
D
Safety-relate
d shutdown
Trigger/cause for safety-related shutdown exists Eliminate the
cause
11010
B
26
D
External fault External (process-related) error, for example:
Sensor error
Actuator error
Sensor data is not correct
Replace the
sensor/actuator;
correct the process
wiring
11011
B
27
D
Indefinable
error
Indefinable errors are errors that cannot be further
specified
Depends on cause
