Getting Started
2-3
Distributed I/O Device ET 200M
EWA-4NEB780600602-06
2.2 Order Numbers for the Sample Configuration
Quan-
tity
Article Order number
(Siemens)
1 Rail e. g.
6ES7 390-1AE80-0AA0
1 Power supply PS 307 with jumper e. g.
6ES7 307-1BA00-0AA0
1 Interface module IM 153-2 6ES7 153-2BA00-0XB0
1 DI module SM 321 e. g.
6ES7 321-7BH00-0AB0
1 DO module SM 322 e. g.
6ES7 322-8BF00-0AB0
2 20-pin front connector with screw-type contacts 6ES7 392-1AJ00-0AA0
X m PROFIBUS cable with bus connector Depends on version
X m Cable for grounding the rail, with 10 mm cross
section and cable lug for M6,
length depends on installation position
Commercially available
Various M6 screws and nuts
(lengths depend on installation position) supplied
with appropriate wrench/screwdriver
Commercially available
1 Screwdriver with 3.5 mm tip Commercially available
1 Screwdriver with 4.5 mm tip Commercially available
1 Side cutter and tool for stripping wires Commercially available
1 Tool for attaching wire end ferrules Commercially available
Appr.
2 m
Stranded wire with 1 mm
2
cross section with
appropriate
wire end ferrules, type A, length 6 mm
Commercially available
2 Single-pole ON button Commercially available
1 Indicator lamp 24 V Commercially available
